It’s important to realize, though, if you create a new ACD file, you will not have documentation in earlier versions of RSLogix / Studio 5000. If you do not have an ACD file for the processor, simply create a new file. This is important for displaying the program’s documentation. If you go online, however, you can monitor the logic without much affect on your system other than increased traffic.
Only download if you know what you are doing. If you download, your system will go down. My processor is in slot 2, but typically, the processor is in slot 0.Īt this point, go online with the processor. You cannot download or go online with any other module. It’s important to realize it’s the PROCESSOR that we need to click on.
Now that we are sure we have communication, go back to RSLogix / Studio 500. Resolve ControlLogix Communication Path Needed In this case, I have a program in the processor called “MCR”, and the processor is in slot 2. It’s important to realize, it’s the PROCESSOR that we are looking for to verify communication. Depending on how you are accessing the processor, you may need to click the + on the driver, and communication module to go across the backplane to see the processor. Once you go to the RSWHO screen (under Communication | RSWHO), you should be able to click on the driver. I will choose the virtual backplane driver. When you plug in your USB cable, you should see the USB Devices driver appear automatically. On the other hand, if you have newer modules, you can connect with USB. In that case, you would consider using the DF1 driver. If you have an older processor, such as the L6x, L55, or L1, you might be using a null modem cable to connect to the serial port. When connecting over Ethernet, use the Ethernet Devices driver, or the Ethernet/IP driver. If you have not already done so, you need to set up a communication driver in RSLinx. At the same time, even if it did know the IP address, it would not know what slot the processor is in. The reason you get this error is because RSLogix / Studio 5000 does not know the IP address of the ControlLogix chassis on your network. Meanwhile, let’s take a look at your PATH in the toolbar area. The reason for this error is that RSLogix / Studio 5000 does not know how to connect to your processor. FactoryTalk View SE Trends and Data Log.
